Solar Power Anywhere
The Beginner DIY Solar Power Kit is a quick and easy way to be up and running with solar power anywhere. It comes with all the necessary cables, connectors and components.
It's a convenient way to get power to:
It's a convenient way to get power to:
- Sheds
- Cabins
- Campsites
- Gazebos
- Or anywhere else you need power!
What It Can Power
Refrigerator
Small space heater
Evaporative cooler
TVs
Lights
Drones
The Components
Main Kit Components
Lion 100 Solar Panel
The Lion 100 is a foldable, durable, portable, and easy-to-connect 100W solar panel that lasts up to 20 years. It has a max power output of 18V @ 5.56A and you can link multiple panels together.
Savanna IV
The Savanna IV is a 400W power inverter.
It connects to the 12v Safari UT™ 250 battery
and provides usable plugs and ports for powering all your devices.
It has 2 AC plugs (110V) and 4 USB ports.
It connects to the 12v Safari UT™ 250 battery
and provides usable plugs and ports for powering all your devices.
It has 2 AC plugs (110V) and 4 USB ports.
Savanna CC
The Savanna CC is a solar charge controller.
It regulates the flow of power coming in from
the solar panel to the Safari UT™ 250 battery.
It has a connection input for the the solar panel(s), an output
to go to the battery and charging indicator status lights.
It regulates the flow of power coming in from
the solar panel to the Safari UT™ 250 battery.
It has a connection input for the the solar panel(s), an output
to go to the battery and charging indicator status lights.
25' Anderson™ Extension Cable
The 25’ Anderson™ extension cable
hooks up between the solar panel and
the other electronics.
With the extra distance you have the flexibility to position your solar panel wherever you need to catch the best sunlight while the charge controller and battery sit in the shade.
hooks up between the solar panel and
the other electronics.
With the extra distance you have the flexibility to position your solar panel wherever you need to catch the best sunlight while the charge controller and battery sit in the shade.
Battery Options
Your Battery or Ours
Choose the 'No Battery' option if you already have your own battery,
or use one of our amazing Safari UT Lithium Iron Phosphate (LiFePO4) batteries.
or use one of our amazing Safari UT Lithium Iron Phosphate (LiFePO4) batteries.
Beginner DIY Solar Power Kit Specs
Lion 100 - 100W 12 V Foldable Solar Panel
‣ Heavy Duty Double Walled Aluminum Construction
‣ Easily Portable Folding Panels with an Easy-to-Carry Handle
‣ Anti-Corrosive Monocrystalline Solar Cells that Last up to 20 years
‣ Expandable - Link up to 4 Panels
‣ Max Power Output - 18V @ 5.56A
‣ Dimensions Folded - 26.5 x 20 x 2
‣ Dimensions Open - 26.5 x 40 x 1
‣ Weight - 20 Pounds
‣ Warranty - 1 Year
Savanna CC - Solar Panel Charge Controller
‣ Regulates the power flow between your solar panels and battery.
‣ 12 Volt, 20 Amp PWM Charge Controller
Savanna IV - 400 Watt Power Inverter
‣ Connects directly to your battery and provides power for your devices.
‣ Outputs - 2 AC and 4 USB (2 @ 2.4A, 1 @ 1A and 1 @ 0-2.4A)
‣ Output Voltage - 110VAC+/-5% / 60Hz (US)
25' Andersion Extension Cable
‣ Position your Solar Panels for best exposure to the sun while keeping the rest of your equipment tucked away.
‣ Length - 25'
‣ Rated for - 12V, 30A
Lion Safari UT 250
‣ Lithium-ion Iron Phosphate
‣ Zero Maintenance
‣ Holds charge for over a year
‣ Weighs just over 5 pounds
‣ Covered by a 7 Year Limited Warranty
‣ 12.8V, 20Ah, 250Wh
‣ Dimensions - 7.1” L x 3.0” W x 6.6” H
‣ Standard Charge Current - 10 A
‣ Max Charge Current - 30 A
‣ Max Charge Voltage - 14.8 V
‣ Max Continuous Discharge Current - 35 A
‣ Operation Temperature - -4 to 130ºF
‣ Charge Temperature - 32 to 110ºF
Lion Safari UT 700
‣ Lithium-ion Iron Phosphate
‣ Zero Maintenance
‣ Holds charge for over a year
‣ Weighs just 15.6 pounds
‣ Covered by a 10 Year Limited Warranty
‣ 12.8V, 56Ah, 716Wh
‣ Dimensions - 10.2” L x 8.8” W x 6.6” H
‣ Standard Charge Current - 25 A
‣ Max Charge Current - 50 A
‣ Max Charge Voltage - 15.4 V
‣ Max Continuous Discharge Current - 100 A
‣ Operation Temperature - -4 to 130ºF
‣ Charge Temperature - 32 to 110ºF
Lion Safari UT 1300
‣ Lithium-ion Iron Phosphate
‣ Zero Maintenance
‣ Holds charge for over a year
‣ Weighs just 23 pounds
‣ Covered by a Limited Lifetime Warranty
‣ 12.8V, 105Ah, 1344Wh
‣ Dimensions - 10.2” L x 8.8” W x 6.6” H
‣ Standard Charge Current - 75 A
‣ Max Charge Current - 100 A
‣ Max Charge Voltage - 14.6 V
‣ Max Continuous Discharge Current - 150 A
‣ Operation Temperature - -4 to 130ºF
‣ Charge Temperature - 32 to 110ºF
 |
